metal picture frame screen

The YUETMEI metal screen utilizes imported PVC raw materials as its base material. It undergoes initial shaping by a professional high-precision screen machine and is then processed with a specialized surface engraved with micro diamond patterns. This screen surface boasts a delicate texture, smooth and glossy quality, effectively eliminating light ripples and enhancing the surface's diffuse reflection function. During projection, the reflectivity of the light-receiving surface is extremely low, resulting in rich and delicate shades, high contrast, vibrant and bright colors without glare, and a pronounced depth of field, full of three-dimensional texture. The effective viewing angle reaches up to 150 degrees, truly restoring true colors. The screen surface is soft and flat, resistant to deformation, and features a pure color tone. This imported metal soft screen is characterized by high brightness, high contrast, and high gain, making it suitable for 3D, 4D, and 5D screenings. The product is fireproof, flame retardant, mold-resistant, and environmentally friendly. It has been widely applied to various image display environments such as performance and entertainment centers, villa cinemas, and various large-scale theater stages. It is easy to use and clean.

Screen parameters:

Projection method: front projection
Roughness:<18μm
Uniformity: 99.9%
Optical gain: 2.45
Horizontal viewing angle: 145°
Vertical viewing angle: 140°
Flame retardant performance: (UL94 V-0 level)
Good color reproduction performance, with reflected light and incident light having consistent chromaticity
Screen resolution ≧125 lines per mm
Color temperature difference: 5400K+100K
Tensile strength: maximum 160 kg/cm², average 150 kg/cm²
Tear strength: maximum 95 kg/mm, average 90 kg/mm
Expansion rate: maximum 20%, average 15%
Heat shrinkage: 10%
Thickness: 0.28mm
